MPA Rimfire Elite Barreled Action

The Masterpiece Arms Rimfire Elite Barreled Action stands as a pinnacle of reliability, performance, and accuracy, utilised by elite shooters globally. Backed by unparalleled customer support and a dedicated support team, it comes with enhanced engineering and performance documentation to maximise shooters’ potential in all rimfire competitive environments.

This Build

• Barrel Contour: MPA Match
• Barrel Thread: Crowned – No Thread
• Barrel Tuner: No
• Barrel Length: 24″
• Twist Rate: 1:16
• Trigger: TriggerTech Diamond
• Handedness: Right Handed

Barrel

Barrels are made from 416 stainless steel, hand-lapped and hand-chambered. Each chamber is machined to run both Eley and Lapua length rim thickness, allowing consistent ignition across precision-oriented rimfire ammunition. Crush on the projectile is optimised by engaging the second drive band on the bullet across multiple bullet types, enhancing accuracy performance.

Receiver

• Remington 700 footprint
• Integral recoil lug
• 30 MOA Picatinny rail
• 1 1/16-16 UN-2A barrel thread
• AICS Rimfire mag compatible
• 60-degree bolt throw
• Adjustable trigger hanger
• Robust, 11 o’clock bolt release
• Black nitride finish
• Fixed ejector

Bolt

• 2-lug design
• Reliable, proven pad-and-hook extractor design
• Controlled-round-feed extractor with ability to push/single feed
• Standard 5/16-24 UNF 2A bolt knob thread
• Black nitride finish

Chamber

• Reamer lead angle: 1.5 degree
• Crush optimised by engaging the 2nd drive band on the bullet across multiple bullet types
• Rim thickness range: .037″–.043″
