MDT Metal Magazine – 6mm – 12 Round – With Binder (please check your State legislation regarding 12 RND capacity)

• 12-Round Magazines for 6mm:
• 3.055” Outside Length
• 2.570” max cartridge overall length (COAL) with binder plate and spacer
• 4.61” Rear Height

MDT AICS-pattern metal magazines are manufactured from high strength steel, nitride-finished and coated with Cerakote Elite for ultimate durability and performance.

The short action magazines are offered for .308 Win and 6.5 Creedmoor family cartridges.

The 6mm BR magazine is offered for the 6mm BR and family of cartridges, and are available in 12 round capacity.

These magazines are designed with a unique Double Stack to Single Feed (DSSF) transition design for reduced overall height compared to the industry standard.

6MM Caliber Mag

From testing, we have established that these magazines will work with the following calibers:

• 6mm BR Norma
• 6mm BRA
• 6mm BRX
• 6 mm Dasher
• 22 BR

Additionally, through testing, we have found that these magazines ARE NOT COMPATIBLE WITH the following actions:

• Curtis Custom’s Axiom and Vector
• GAP Tempest
• Ultimatum Deadline
• and most other commonly available, aftermarket 3-lug actions

Details

MDT AICS-pattern metal magazines are manufactured from high strength steel, nitrided, and finished inside and outside with Cerakote Elite for ultimate durability, corrosion resistance, and friction reduction.

Binder Plate Details

The magazines without front binder plates allow a maximum cartridge overall length of 2.960”. These are compatible with all AICS-pattern bottom metal and chassis systems, but most common actions such as Remington 700 and Savage 10/11 will require modifications to the receiver (i.e. notching out the bottom of the feed ramp) to prevent the bullet tips from catching on the bottom of the feed ramp (see photo below). DO NOT order these magazines without a full understanding of this.
